Power Requirements

DC +5V, External power, 5~12VDC unregulated power (max. 65mA, typical 55mA, 50mV peak to peak max ripple)

Operating Temperature

-40 to85℃

Storage Temperature

-40 to90℃

Relative Humidity

95% at60℃

Interface

Auto - detection:

1. RS232: 9600 bauds, None parity, 8 data bits, 1 stop bit.

2. USB: USB 2.0 compliant, full speed

Resolution

2048 x 2048

Accuracy Tolerance

Max. +/- 1%

Report Rate

Max.180 points/sec

Response Time

Max. 25 ms

Regulatory Approvals

FCC-B, CE

Green Product

RoHS

Pin Out Definition

UL, UR, COM, LR, LL

ESD

± 27 KV Air, ± 8 KV Contact
